Monitor Audio W180 In-Wall Speaker – Two-Way Configuration With Gold-Dome Tweeter – Low-Profile Black Build

Description

Monitor Audio W180 In-Wall Speaker

The W180 incorporates an 8-inch MMP II bass driver with Monitor Audio’s signature C-CAM Gold Dome tweeter to provide high performance sound, ease-of-drive, and wide frequency response and dispersion.
Optimum imaging and set-up are established via a pivoting tweeter and high-frequency (+3 dB / 0 dB /-3 dB) level adjustment.
Specification
Frequency Response50 Hz – 25 kHz
Nominal Impedance6 ohms
Sensitivity (1W@1M)90 dB
Maximum SPL111.6 dBA
Power Handling (RMS)120 W
Recommended Amplifier Requirements30 – 120 W
Drive Unit Complement

• 8″ MMP II cone bass driver
• 1″ C-CAM Gold Dome tweeter

Adjustment ControlsHF Level Switch (+3 dB / 0 dB / -3 dB)
Overall Diameter (Including Grille)441 x 288 mm (173/8 x 115/16″)
Overall Depth (Including Grille)104 mm (41/8″)
Mounting Depth100 mm (315/16″)
Cut-Out Hole Diameter387 x 234 mm (151/4″ x 93/16″)
Fixing Type6 position Tri-Grip dog fixings
Construction MaterialMineral filled ABS, RoHS compliant
Weight3.08 kg (6 lb 12 oz)
Pre-Construction BracketWB8 Pre-Construction Bracket (Green)
Back BoxWCBOX-L
