Monitor Audio W165 In-Wall Speaker – Slim Profile Installation – Discreet Black Frame & Grille

Description

Monitor Audio W165 In-Wall Speaker

The W165 incorporates a 6 1/2″ MMP II bass driver with Monitor Audio’s signature C-CAM Gold Dome tweeter to provide high performance sound, ease-of-drive, and wide frequency response and dispersion.
Optimum imaging and set-up are established via a pivoting tweeter and high-frequency (+3 dB / 0 dB /-3 dB) level adjustment.
Specification
Frequency Response60 Hz – 25 kHz
Nominal Impedance6 ohms
Sensitivity (1W@1M)88.5 dB
Maximum SPL107.4 dBA
Power Handling (RMS)65 W
Recommended Amplifier Requirements20 – 65 W
Drive Unit Complement

• 6 1/2″ MMP II cone bass driver
• 1″ C-CAM pivoting Gold Dome tweeter

Adjustment ControlsHF Level Switch (+3 dB / 0 dB / -3 dB)
Overall Diameter (Including Grille)370 x 250 mm (149/16 x 913/16″)
Overall Depth (Including Grille)96 mm (33/4″)
Mounting Depth92 mm (35/8″)
Cut-Out Hole Diameter332 x 213 mm (131/16 x 83/8″)
Fixing Type6 position Tri-Grip dog fixings
Construction MaterialMineral filled ABS, RoHS compliant
Weight2.21 kg (4 lb 14 oz)
Pre-Construction BracketWB6 Pre-Construction Bracket (Purple)
